Brake Disc Standard

Filter by brand
DISPLAYING 1 to 8 (of 8 products)
Special Order item
9Y0615601
Product Information
Product Information
Brake disc rotor REAR.
Fits Left or Right. Sold each.

Fits:
Porsche 9YA Cayenne 2018>>
For cars with Rear brake discs 18", brake caliper painted Black (option code: 1KV)
Porsche 9YA Cayenne E-Hybrid 2018>>
For cars with Rear brake discs 18", brake caliper painted Green (option code: 1KR)

Please note: OE brake discs and brake pads are not stocked items and fall under special order terms.


Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

9Y0615601
9Y0615601
460.4523.20

The product you are viewing cross references to these numbers
9Y0615601ABS
Product Information
Product Information
Brake disc rotor REAR.
Fits Left or Right. Sold each.

Diameter Ø: 330 mm
Thickness: 26 mm
Total height:  73,6  mm

Fits:
Porsche 9YA Cayenne 2018>>
For cars with Rear brake discs 18", brake caliper painted Black (option code: 1KV)
Porsche 9YA Cayenne E-Hybrid 2018>>
For cars with Rear brake discs 18", brake caliper painted Green (option code: 1KR)




Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

9Y0615601ABS
9Y0615601

The product you are viewing cross references to these numbers
9Y0615601BRE
Product Information
Product Information
Brake disc rotor REAR,  Ventilated, 330 x 26 mm.
Fits Left or Right. Sold each.

Fits:
Porsche 9YA Cayenne 2018>>
For cars with Rear brake discs 18", brake caliper painted Black (option code: 1KV)
Porsche 9YA Cayenne E-Hybrid 2018>>
For cars with Rear brake discs 18", brake caliper painted Green (option code: 1KR)

Brake Disc Ø: 330 mm
Thickness: 26mm
Brake disc type: Ventilated
Height: 74mm

Note:
Brake disc rotors are priced each.

The Brembo brake disc with special UV paint treatment guarantees superior corrosion resistance for the product, thanks to the protective coating on the outer edges and on the disc hub. The UV paint not only gives the disc a clean, shiny appearance but is also beneficial for the environment as the water-based UV paint treatment does not require the use of chemical solvents and is a low energy consumption process.

•   OE-equivalent
•   Brembo quality
•   ECE-R90 certificate
•   Safety
•   High carbon
•   Anti-corrosion
•   Fastening screws

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

9Y0615601BRE
9Y0615601
460.4523.20
09.C988.21

The product you are viewing cross references to these numbers
Special Order item
9Y0615601B
Product Information
Product Information
Brake disc rotor, REAR.
Fits Left or Right. Sold each.

porsche

Fits:
Porsche 9YA Cayenne 2018>> - REAR
(1KS) - For cars with Rear brake discs 18", brake caliper painted Green
(2EI) - For cars with Rear brake discs 18", brake caliper painted Black
(2EN) - For cars with Rear brake discs 19", brake caliper painted Red

Porsche (9J1) Taycan 2020>>
Cars with Basic equipment, Rear brake discs 17", brake caliper painted Black

Porsche (9J1) Taycan 2020>>
Cars with Sports equipment (A8F), Rear brake discs 18", brake caliper painted Red

Please note: OE brake discs and brake pads are not stocked items and fall under special order terms.


Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

9Y0615601B
9Y0615601B

The product you are viewing cross references to these numbers
Special Offer
9Y0615601BZIM
Product Information
Product Information
Zimmermann REAR Standard Coat Z Brake disc rotor.

Fits:
Porsche 9YA Cayenne 2018>> - REAR
(1KS) - For cars with Rear brake discs 18", brake caliper painted Green
(2EI) - For cars with Rear brake discs 18", brake caliper painted Black
(2EN) - For cars with Rear brake discs 19", brake caliper painted Red

Porsche (9J1) Taycan 2020>>
Cars with Basic equipment, Rear brake discs 17", brake caliper painted Black

Porsche (9J1) Taycan 2020>>
Cars with Sports equipment (A8F), Rear brake discs 18", brake caliper painted Red

Please note: Those discs are not sided. They fit left or right side of the car. Brake disc rotors are priced each.

Internally Vented, Coated
Outer diameter: 358 mm
Brake Disc Thickness: 28 mm
Bolt Hole Circle Ø: 130 mm
Centering Diameter: 98 mm
Weight: 9.8 kg
Hole Pitch / Number: 8/5

Description:

All the brake discs and brake drums in Zimmermann standard range of wearing parts are manufactured in dimensions and to a material quality specified by the automotive manufacturers.

Your advantages:

• Equivalent spare parts as defined by motor vehicle block exemption regulation KFZ-GVO (EU) 330/2010
• Consistently high product quality
• Wide range of Standard Brake Discs with anti-corrosion protection Coat Z
• Over 50 years experience in brake disc manufacture



Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

9Y0615601BZIM
460.4548.20
9Y0615601B

The product you are viewing cross references to these numbers
Special Offer
9Y0698151APBRE
Product Information
Product Information
Brake pads set of 4 for one axle

front
Porsche 9YA Cayenne 3.0ltr V6
Porsche 9YA Cayenne 3.0ltr E-Hybrid V6
Porsche 9YA Cayenne 4.0ltr GTS V8
Porsche 9YA Cayenne 4.0ltr turbo S E-Hybrid V8 4.0ltr
For Option Code -
1ZB Front brake 18" disc brake, caliper painted Green, North America

1ZS Front brake 18" disc brake, caliper painted Black (NAR)

Porsche 95B Macan turbo 3.6ltr - 2014 to 2018
Porsche 95B.2 Macan GTS / turbo 2.9ltr - 2019 to 2021
Porsche 95B.2 Macan S 3.0ltr - 2019 to 2021
For Options - Calipers Red / Grey or White

Porsche 971.2 Panamera 4S E-Hybrid Sport Turismo 2.9ltr V6
Porsche 971.2 Panamera turbo S E-Hybrid 4.0ltr V8
For Option Code - 1LR Front brake disc 18" diameter, brake caliper painted Black



Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

9Y0698151APBRE
95B698151AK
971698151S
9Y0698151S
95B698151AP
9Y0698151AP
971698151AB
9Y0698151P
971698151AE

The product you are viewing cross references to these numbers
Special Offer
TEXCERA
Product Information
Product Information
Cera-Tec metal free permanent lubricant Textar


textar

For brake systems and is highly temperature-resistant (up to 1,000°C).

Available in 75ml tube and 5ml sachet

The advantages of Cera Tec:
• Non-conductive and contains no solids
• Suitable for ABS
• Facilitates brake installation
• Reduces brake squealing
• Protects against scoring and corrosion
• Free of copper and acids
• Pressure-resistant / high viscosity

Cera Tec is also suitable for lubricating:• Disc- and drum-brake systems
• Compressors
• Centralised lubrication systems
• Axle bearings
• Chains
• Seat rails
• Sunroof tracks
• Battery terminals

Application:
Apply a thin layer of Cera Tec on the marked sections




Find out about Textar product verification here
Special Offer
96000100
Product Information
Product Information
Textar Brake Cleaner removing oil, grease and dirt 500ml

textar


• brake, clutch and gear components
• starter motors and alternators
• carburetors, fuel pumps and engine components
• glass and metal surfaces before gluing

The advantages of Textar brake cleaner:
• does not destroy polystyrene
• does not contain any chlorinated solvents
• is listed with the German Federal Ministry for the EnvironmentHow to use:

Spray a thick coating on the parts to be cleaned. Allow the solvent to drip and/or evaporate. Repeat if necessary.



Find out about Textar product verification here

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

96000100
96000100

The product you are viewing cross references to these numbers
DISPLAYING 1 to 8 (of 8 products)
About Brake Disc Standard

Porsche Standard Brake Discs | Design911 Precision Replacement Parts for Safety, Control & Everyday Performance

Standard brake discs are essential components of your Porsche’s braking system, providing the friction surface needed for effective stopping power. Designed for smooth, reliable performance in daily and spirited driving, they work in harmony with brake pads and calipers to deliver consistent, fade-free braking. Replacing worn or damaged brake discs is vital to maintaining your Porsche’s control, safety, and signature driving feel.

At Design911, we supply a comprehensive range of standard brake discs, crafted from high-grade cast iron or carbon-steel composites for strength, precision, and thermal stability. Each disc is engineered to match Porsche specifications for balance, fitment, and performance. Perfect for maintenance, restoration, or road use, our discs ensure your Porsche delivers the braking excellence it was built for — mile after mile.

What Do Standard Brake Discs Do?

Brake discs convert kinetic energy into heat through friction, providing the core braking force that slows or stops your Porsche safely and smoothly.

Core Functions:
• Provide a friction surface for brake pads to engage.
• Dissipate heat to prevent fade and ensure consistent braking.
• Maintain smooth deceleration and vehicle control.
• Enable balanced braking performance across all wheels.
• Support stability and confidence in all driving conditions.

Precision-engineered brake discs are vital for dependable stopping performance and driver confidence on both road and track.

Why Do Standard Brake Discs Fail or Degrade?

Brake discs are constantly subjected to high temperatures, friction, and environmental stress, which can cause wear or damage over time.

Common Causes of Failure Include:
• Surface wear and scoring from aged or contaminated pads.
• Heat cracks or warping from excessive braking temperatures.
• Corrosion from moisture or road salt exposure.
• Thickness variation leading to vibration or pulsation.
• Prolonged use beyond recommended wear limits.

When discs degrade, braking performance and safety are compromised — resulting in longer stopping distances and potential instability under load.

Why Replace or Upgrade Your Porsche Standard Brake Discs?

Replacing worn brake discs ensures optimum braking efficiency, control, and safety. Design911’s precision-engineered discs are designed to meet or exceed original specifications, providing consistent braking feel and reliability across all Porsche models.

Key Benefits:
• Restores smooth and efficient braking performance.
• Reduces stopping distance and vibration.
• Constructed from high-strength, thermally stable materials.
• Corrosion-resistant coatings for extended lifespan.
• Direct-fit replacements for perfect alignment and operation.
• Ideal for road use, restoration, or performance servicing.

Design911’s Porsche standard brake discs deliver performance, durability, and safety — ensuring your Porsche continues to brake as confidently as it accelerates.

Highlights

• Premium Porsche standard brake discs for all models.
• Precision-balanced and machined for vibration-free braking.
• Resistant to warping, corrosion, and heat fade.
• Ideal for daily driving, maintenance, or restoration.
• Exact-fit compatibility across Porsche’s model range.
• Engineered for performance, safety, and longevity.
