Brake disc rotor, FRONT. Standard Coat Z. Porsche 971.1 / 971.2 / 976 Panamera (OE Part No. 971615301L / 971615302L) - 97161530
Zimmermann
97161530
Product Information
Internally Vented, Slotted, Coated
Outer diameter: 360 mm
Brake Disc Thickness: 36 mm
Bolt Hole Circle Ø: 130 mm
Centering Diameter: 98 mm
Weight: 13.1 kg
Hole Pitch / Number: 7/5
Porsche 971.1 Panamera 2017 - 2021 - FRONT
(I1LU) For cars with 18-inch brake disc, brake caliper in anodised silver
(I1LD) For cars with 18-inch brake disc, brake caliper painted Silver, (North America)
Porsche 971.2 Panamera 2021 - 2023 - FRONT
(A8F) "S" equipment
(0J2) Load group 1 FA/1 RA
Porsche 976 Panamera 2024>> - FRONT
18-inch brake disc, brake caliper black
(FM0) - Basic
(0J2) - Standard payload
Description:
All the brake discs and brake drums in Zimmermann standard range of wearing parts are manufactured in dimensions and to a material quality specified by the automotive manufacturers.
Your advantages:
• Equivalent spare parts as defined by motor vehicle block exemption regulation KFZ-GVO (EU) 330/2010
• Consistently high product quality
• Wide range of Standard Brake Discs with anti-corrosion protection Coat Z
• Over 50 years experience in brake disc manufacture
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
97161530
The product you are viewing cross references to these numbers
Product Information
Zimmermann Standard Coat Z Brake disc rotor.Internally Vented, Slotted, Coated
Outer diameter: 360 mm
Brake Disc Thickness: 36 mm
Bolt Hole Circle Ø: 130 mm
Centering Diameter: 98 mm
Weight: 13.1 kg
Hole Pitch / Number: 7/5
Porsche 971.1 Panamera 2017 - 2021 - FRONT
(I1LU) For cars with 18-inch brake disc, brake caliper in anodised silver
(I1LD) For cars with 18-inch brake disc, brake caliper painted Silver, (North America)
Porsche 971.2 Panamera 2021 - 2023 - FRONT
(A8F) "S" equipment
(0J2) Load group 1 FA/1 RA
Porsche 976 Panamera 2024>> - FRONT
18-inch brake disc, brake caliper black
(FM0) - Basic
(0J2) - Standard payload
Description:
All the brake discs and brake drums in Zimmermann standard range of wearing parts are manufactured in dimensions and to a material quality specified by the automotive manufacturers.
Your advantages:
• Equivalent spare parts as defined by motor vehicle block exemption regulation KFZ-GVO (EU) 330/2010
• Consistently high product quality
• Wide range of Standard Brake Discs with anti-corrosion protection Coat Z
• Over 50 years experience in brake disc manufacture
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
97161530
460.4506.20
460.4507.20
971615301L
971615302L
971615301F
971615302F
The product you are viewing cross references to these numbers
Vehicle Group
Vehicle Group
- Porsche 971.1 Panamera V6 3.0L 2WD (330 Hp) 2017-20
- Porsche 971.1 Panamera 4 V6 3.0L 4WD (330 Hp) 2017-20
- Porsche 971.1 Panamera 4 V6 3.0L 4WD Executive 2017-20
- Porsche 971.1 Panamera 4 3.0L Turbocharged V6 Sport Turismo 2017-20
- Porsche 971.1 Panamera 4S V6 3.0L 4WD (440 Hp) 2017-20
- Porsche 971.1 Panamera 4S V6 3.0L 4WD Executive 2017-20
- Porsche 971.1 Panamera 4S 2.9L Twin-Turbo V6 Sport Turismo 2017-20
- Porsche 971.1 Panamera 4S Diesel V8 4.0L 4WD (422 Hp) 2017-18
- Porsche 971.1 Panamera 4S Diesel 4.0L Twin-Turbo V8 Sport Turismo 2017-18
- Porsche 971.1 Panamera Turbo V8 4.0L 4WD (550 Hp) 2017-20
- Porsche 971.1 Panamera Turbo V8 4.0L 4WD Executive 2017-20
- Porsche 971.1 Panamera Turbo 4.0L Twin-Turbo V8 Sport Turismo 2017-20
- Porsche 971.1 Panamera Turbo S E-Hybrid V8 4.0L 4WD 2017-20
- Porsche 971.1 Panamera Turbo S E-Hybrid V8 4.0L 4WD Executive 2017-20
- Porsche 971.2 Panamera 4S 2.9L V6 2021-23
- Porsche 971.2 Panamera 4S Sport Turismo 2.9L V6 2021-23
- Porsche 976 Panamera V6 2.9L 2023>>
- Porsche 976 Panamera 4 V6 2.9L 2023>>
Select side
Prices from: €179.54 inc. VAT
Shop Securely
12 Month Warranty
Worldwide Delivery
