Lubrificazione motore/Serbatoio olio - 9770 - 997.2 GT2 RS 3.6L 2010-11 - PORSCHE

Fai clic sui numeri delle immagini per visualizzare le info del prodotto

Diagram 104-007 Porsche Cayman 718 (982) 2017>> Motore SKU: 99720707072, serbatoio dell'olio SKU: 99320722600, foca SKU: 99620715073, pezzo intermedio SKU: 90037700901, dado esagonale m5 SKU: 99620721270, flangia SKU: 99970734341, anello or 25,07 x 2,62 SKU: 99720701670, tubo di riempimento SKU: 99970748140, o-ring 24x3,0 SKU: 99610703552, tappo di chiusura SKU: 99610733600, foca SKU: 99720721673, staffa per tubo di riempimento SKU: 99907318901, bullone testa tonda piatta m 6 x 12 SKU: 90038505001, bullone a testa esagonale m 6 x 16 SKU: 90038527501, vite torx m6x20 SKU: 90038527501, vite torx m6x20 SKU: 99660614002, sensore del livello dell'olio SKU: 99970219340, passacavo in gomma 17,0 x 24,0 x 1,8 SKU: 99970219340, passacavo in gomma 17,0 x 24,0 x 1,8 SKU: 99970219340, passacavo in gomma 17,0 x 24,0 x 1,8 SKU: 99920903701, manicotto distanziale 8,4 x 1,8 SKU: 99920903701, manicotto distanziale 8,4 x 1,8 SKU: 90038511601, vite torx m8x30 SKU: 90038511601, vite torx m8x30 SKU: 90038511601, vite torx m8x30 SKU: 99720741771, staffa SKU: 90012301020, anello di tenuta SKU: 90006501800, tappo di chiusura SKU: WHT001703, vite torx m8x35 SKU: PAF001704, vite torx m8x20 SKU: 99970731641, anello or 21,89 x 2,62 SKU: 99620701274, collegamento di aspirazione SKU: 99970736441, anello di tenuta 30 x 2,5 SKU: 99720703771, linea di sfiato SKU: 99720713971, tubo di ventilazione del serbatoio SKU: 99951265209, fascetta stringitubo 19 x 12 SKU: 99951265109, fascetta stringitubo 15 x 12 SKU: 99720714371, tubo di sfiato SKU: 99951225201, fascetta stringitubo 23 - 35/9 SKU: 99620720773, pezzo distanziatore SKU: 99620720674, pezzo distanziatore SKU: 90024906101, bullone a testa svasata m 12 x 40 SKU: 90024906101, bullone a testa svasata m 12 x 40 104-007
